Model No: TM-1942-S
19inch PCAP touch monitor
19inch PCAP Project Capacitive Open Frame Touch Monitor
Quantity :
TM-1942-S19inch project capacitive open frame touch monitor, plastic front bezel, inside PCAP touch meet IP65 waterproof, Highlight display with anti-vandal tempered cover glass, which is designed for Kiosks, Interactive digital signage, ATM, Gaming, Casino, Industrial, Education etc., is easily connected and installed by user.
FEATURES
Professional LCD panel, horizontal or vertical On-Screen Display (OSD) Multitouch10Point project capacitive touch technology Anti-vandal tempered cover glass | VGA, DP, HDMI Video Input IP65 waterproof and dustproof Standard VESA mounting and four side bracket options Multi-interface apply to various connection |
Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.
TM-1942-S 19" PCAP Open Frame Touch Monitor Specification | ||
Model | TM-1942-S | |
Description | 19"4:3 Open Frame PCAP Multitouch Touch Monitor | |
Case/Bezel Color | Steel/Black | |
Display | 19inch Active matrix TFT LCD | |
| Aspect Ratio | 4:3 | |
Optimal (native) Resolution | 1280×1024 | |
Useful Screen Area | 377.32mm × 302.06mm | |
Colors | 16.7 M | |
Brightness | 250nits（500/1000/1500nits options) | |
Contrast Ratio | 1000:1 (Typical) | |
Viewing Angle(CR≥10) | Horizontal: ±85° or 170° total; Vertical: ±80° or 160° total | |
Input Video Format | VGA, DP, HDMI Option | |
Input Video Signal Connector | VGA, DP, HDMI Option | |
| On Screen Display | Controls (back):on/off, Menu, Left, Right, Auto | |
| Backlight Lamp Life | 50000 hrs | |
| Touch | Touch Technology | Projected Capacitive Touch Technology, Ture 10-40points Multitouch |
| Response Time | 3ms | |
| Touch Resolution | 32767×32767 | |
| Touch Glass | 2mm Anti-vandal tempered glass | |
| Sealability | Touchscreen sealed to Plastic-bezel IP65 | |
| Touchscreen sealed to LCD | ||
| MTBF | 50000 hrs demonstrated | |
Touch Interface | USB touch interface | |
| Support OS | HID Mode: Windows 7/8/10/11, Linux, Android, Raspberry Pi, MAC, etc. | |
Mounting Options | VESA Mount (75mm or 100mm) , Side Mount or Front Mount with optional bracket | |
| Power Supply | 12V DC, (24V DC POE Option) External Adapter: 100-240VAC, 50-60Hz | |
Temperature Range | Operating: 0℃ to 50℃; Storage: -20℃ to 60℃ | |
Humidity Range (no condensing) | Operating: 20%-80%; Storage: 10%-90% | |
Dimension and Weight | Touch Monitor 429.36 x 356.98 x 45mm | |
Warranty | 1 year | |
Agency Approvals | CCC, FCC, CE, RoHS | |
