Model No: TM-2152D
21.5inch PCAP touch monitor
21.5inch PCAP Project Capacitive Desktop Touch Monitor
Quantity :
TM-2152D 21.5inch project capacitive desktop touch monitor, Aluminum alloy front bezel, inside PCAP touch meet IP65 waterproof, Highlight display with anti-vandal tempered cover glass meet IK07, Suitable for outdoor application, which is designed for Kiosks, Interactive digital signage, ATM, Gaming, Casino, Industrial, Education etc., is easily connected and installed by user.
FEATURES
| Zero-bezel flat touch computer, slim housing Professional LCD panel, horizontal or vertical On-Screen Display (OSD) Multitouch10Point project capacitive touch technology | 3mm anti-vandal tempered cover glass meet IK07 Aluminum alloy front bezel, meet IP65 waterproof Full HD 1920×1080 Standard VESA mounting and four side bracket options |
Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.
TM-2152D 21.5"PCAP Open Frame Touch Monitor Specification | ||
Model | TM-2152D | |
Description | 21.5"IP65 Desktop PCAP Multitouch Touch Monitor | |
Case/Bezel Color | Steel/Black | |
Display | 21.5inch Active matrix TFT LCD | |
| Aspect Ratio | 16:9 | |
Optimal (native) Resolution | 1920×1080 @60HZ | |
Useful Screen Area | 476mm × 267.5mm | |
Colors | 16.7 M | |
Brightness | 350nits（500/1000/1500nits options) | |
Contrast Ratio | 1000:1 (Typical) | |
| I/O Ports | USB Touch, VGA, HDMI, DisplayPort, 12V D/C in | |
Viewing Angle(CR≥10) | Horizontal: ±89° or 178° total; Vertical: ±89° or 178° total | |
Input Video Format | HDMI, VGA & Display Port Option | |
Input Video Signal Connector | HDMI, VGA & Display Port Option | |
| On Screen Display | Controls (back):on/off, Menu, Left, Right, Auto | |
| Backlight Lamp Life | 50000 hrs | |
| Touch | Touch Technology | Projected Capacitive Touch Technology, Ture 10-40points Multitouch |
| Response Time | 3ms | |
| Touch Resolution | 32767×32767 | |
| Touch Glass | 3mm Anti-vandal tempered glass meet IK07 | |
| Sealability | Touchscreen sealed to Aluminum alloy-bezel IP65 | |
| Touchscreen sealed to LCD | ||
| MTBF | 50000 hrs demonstrated | |
Touch Interface | USB touch interface | |
| Support OS | HID Mode: Windows 7/8/10/11, Linux, Android, Raspberry Pi, MAC, etc. | |
Mounting Options | VESA Mount (75mm or 100mm) , Side Mount or Front Mount with optional bracket | |
| Power Supply | 12V DC, (24V DC POE Option) External Adapter: 100-240VAC, 50-60Hz | |
Temperature Range | Operating: 0℃ to 50℃; Storage: -20℃ to 60℃ | |
Humidity Range (no condensing) | Operating: 20%-80%; Storage: 10%-90% | |
Dimension and Weight | Touch Monitor 518 x 313 x 53.5mm | |
Warranty | 1 year | |
Agency Approvals | CCC, FCC, CE, RoHS | |
