Model No: PF2152BM
21.5inch Touch film
Capacitive Multi touch touch foil/Touch Film
Quantity :
Capacitive Multi touch touch foil/Touch Film Specification
Size | 21.5 inch(10"-300"are for optional, support customization) |
| Model | PF2152BM |
| Active Area | 481.34×273.46mm |
| Foil Size | 498.37×291.88mm |
| Structure | Film+Micro Copper Wire+Film |
| Base Material | PET Film |
| Lamination Method | Wet Lamination (OCA) |
| Lamination Substrate | Glass/Acrylic/PMMA or other non-metallic material |
| Inductive Method | Improved projected capacitive technology |
Touch Point | 10 touch points |
Touch deviation | 0.5mm |
Film thickness | Almost 100um |
Light transmittance | 95% |
Safe distance | 3mm/the distance between the LCD screen and the film |
| Frame scan frequency | 120FPS |
Transmission mode | USB 2.0/USB 3.0 |
Supply voltage | 5V |
Drive Type | Driver-free, plug-n-play |
| OS Compatibility | Windows XP, 7/8/10/11, Android, Linux, MAC OS |
Touch support | Click, drag, zoom, rotate |
| Working Temp | -15 ℃ to + 75 ℃ |
| Working Humidity | 0-95% |
Packing list | 1 * Touch film circuit control board * 1 USB cable * 1 |
