Model No: TM-1578

15inch IR touch monitor

15inch infrared multitouch IP65 Open Frame Touch Monitor

Quantity :

Contact Now

TM-1578 is 15inch infrared multitouch IP65 open frame touch monitor, cost-effective touch solution which designed for outdoor application. Application for ATM, Gaming, Casino, Interactive digital, Industrial, Kiosk, etc., is easily connected and integrated by user.

FEATURES

Superb cosmetic, slim housing;
On-Screen display (OSD);
Front bezel meet IP65 waterproof and dustproof;

3mm anti-vandal tempered glass meet UL60950;
Anti-sunlight, any angle on sunlight work well;
Multitouch 4 Point infrared touch technology;
Standard VESA hole and four-side brackets.

Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.

TM-1578 15"IP65 Infrared Open Frame Touch Monitor Specification
Model	TM-1578
Description	15"IP65 Open Frame Infrared Multitouch Touch Monitor
Case/Bezel Color	Metal Shell/Black
Display	15'' diagonal, Active matrix TFT LCD
Aspect Ratio	4:3
Optimal (native) Resolution	1280×1024
Useful Screen Area	308mm × 232mm
Colors	16.7 M
Brightness	450nits（500/1000/1500nits options)
Response Time	5ms (Typical)
Contrast Ratio	700:1 (Typical)
I/O Ports	USB Touch, VGA, DVI, HDMI, 12V D/C in
Viewing Angle(CR≥10)	Horizontal: ±80° or 160° total; Vertical: ±70° or 140° total
MTBF	50000 hrs demonstrated
Input Video Format	VGA, DVI, HDMI Option
Input Video Signal Connector	VGA, DVI, HDMI Option
Touch Technology	Leadingtouch multitouch infrared touch technology
Touch Point	Ture 4point multitouch
Protected Level	IP65(Front bezle) and Anti-vandal 3mm galss meet IK07
Anti-sunligh	Sunlight at any angle, work well, suitable for outdoor applications
Touch Interface	USB touch interface
Mounting Options	VESA Mount (75mm or 100mm) , Four side brackets option
Power Supply	External Adapter: 100-240VAC, 50-60Hz
Temperature Range	Operating: 0℃ to 50℃; Storage: -20℃ to 60℃
Humidity Range (no condensing)	Operating: 20%-80%; Storage: 10%-90%
Dimension and Weight	Touch Monitor 345 x 269 x 46.5mm
Warranty	1 year
Agency Approvals	CCC, FCC, CE, RoHS
