Model No: TM-2295L
21.5inch PCAP touch monitor
21.5inch FHD ELO Compatible PCAP IP65 Open Frame Touch Monitor
Compatible ELO ET2295L
Compatible ELO ET2295L
Quantity :
FEATURES
Full Compatible ELO touch monitor ET2295L; Zero-bezel flat touch monitor, slim housing; High Brightness LED panel, horizontal or vertial; 10Point multitouch project capacitive touch technology | 3mm anti-vandal tempered cover glass meet IK07; Aluminum alloy front bezel meet IP65 waterproof; Anti-glare film option, suitable for outdooor application; Standard VESA mounting and four side brackets options |
Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.
TM-2295L 21.5"FHD ELO Compatible PCAP IP65 Open Frame Touch Monitor Specification | |
Model | TM-2295L |
Description | 21.5"IP65 Open Frame PCAP Multitouch Touch Monitor |
Case/Bezel Color | Steel/Black |
Display | 21.5'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
Optimal (native) Resolution | 1920×1080 |
Useful Screen Area | 477.6mm × 269.1mm |
Colors | 16.7 M |
Brightness | 250cd/m2 |
Pixel Pitch | 276.75(per one triad) x 276.75 |
Response Time | 14ms |
Contrast Ratio | 1000:1 (Typical) |
| I/O Ports | USB Touch, OSD, VGA, HDMI, DisplayPort, 12V D/C in |
Viewing Angle(CR≥10) | Horizontal: ±89° or 178° total; Vertical: ±89° or 178° total |
| MTBF | 50000 hrs demonstrated |
Input Video Format | HDMI, VGA & Display Port |
Input Video Signal Connector | HDMI, VGA & Display Port |
Touch Technology | 10Point multitouch projected capacitive touch technology |
| Touch Point | Ture 10point multitouch |
| Protected Level | IP65(Front bezle) and Anti-vandal 3mm galss meet IK07 Anti-glare film optional, Suitable for outdoor applications(Options) |
Touch Interface | USB touch interface |
Mounting Options | VESA Mount (75mm or 100mm) , Side Mount or Front Mount with optional bracket |
Power Supply | DC:+12VDC ± 5% |
External Adapter: 100-240VAC, 50-60Hz | |
Temperature Range | Operating: 0℃ to 50℃; Storage: -20℃ to 60℃ |
Humidity Range (no condensing) | Operating: 20%-80%; Storage: 10%-90% |
Dimension and Weight | Touch Monitor 521 x 316 x 46.9mm 7KGS |
Warranty | 1 year |
Agency Approvals | CCC, FCC, CE, RoHS |
