Model No: TM-2368

23.6inch IR touch monitor

23.6inch infrared multitouch IP65 Open Frame Touch Monitor

Quantity :

Contact Now

TM-2368 is 23.6inch infrared multitouch IP65 open frame touch monitor, cost-effective touch solution which designed for outdoor application. Application for ATM, Gaming, Casino, Interactive digital, Industrial, Kiosk, etc., is easily connected and integrated by user.

FEATURES

Superb cosmetic, slim housing;
On-Screen display (OSD);
Front bezel meet IP65 waterproof and dustproof;

3-6mm anti-vandal tempered glass meet UL60950;
Anti-sunlight, any angle on sunlight work well;
Multitouch 4 Point infrared touch technology;
Standard VESA hole and four-side brackets.

Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.

TM-2368 23.6" IP65 Infrared Open Frame Touch Monitor Specification
Model	TM-2368
Description	23.6"IP65 Open Frame Infrared Multitouch Touch Monitor
Case/Bezel Color	Metal Shell/Black
Display	23.6"diagonal, Active matrix TFT LCD
Aspect Ratio	16:9
Optimal (native) Resolution	1920×1080 @60HZ
Useful Screen Area	523mm × 295mm
Colors	16.7 M
Brightness	300nits（500/1000/1500nits options)
Response Time	5ms (Typical)
Contrast Ratio	600:1 (Typical)
I/O Ports	USB Touch, VGA, DVI, HDMI, 12V D/C in
Viewing Angle(CR≥10)	Horizontal: ±85° or 170° total; Vertical: ±80° or 160° total
MTBF	50000 hrs demonstrated
Input Video Format	VGA, DVI, HDMI Option
Input Video Signal Connector	VGA, DVI, HDMI Option
Touch Technology	Leadingtouch multitouch infrared touch technology
Touch Point	Ture 6point multitouch
Protected Level	IP65(Front bezle) and Anti-vandal 3mm galss meet IK07
Anti-sunligh	Sunlight at any angle, work well, suitable for outdoor applications
Touch Interface	USB touch interface
Mounting Options	VESA Mount (75mm or 100mm) , Side Mount or Front Mount with optional bracket
Power Supply	External Adapter: 100-240VAC, 50-60Hz
Temperature Range	Operating: 0℃ to 50℃; Storage: -20℃ to 60℃
Humidity Range (no condensing)	Operating: 20%-80%; Storage: 10%-90%
Dimension and Weight	Touch Monitor 564 x 336 x 45.4mm
Warranty	1 year
Agency Approvals	CCC, FCC, CE, RoHS
