Model No: TM-2494L-SAW
23.8inch PCAP touch monitor
23.8inch FHD ELO Compatible SAW Open Frame Touch Monitor
Compatible ELO ET2494L-SAW
Compatible ELO ET2494L-SAW
Quantity :
FEATURES
Full Compatible ELO touch monitor ET2494L-SAW; Economy choice, Reliable quality, Easy operation, widely application; Multi-interface apply to various mounting or connection | Superb cosmetic, slim housing; On-screen display (OSD) Standard VESA mounting and four side brackets options |
Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.
TM-2494L-SAW 23.8"FHD ELO Compatible SAW Open Frame Touch Monitor Specification | |
Model | TM-2494L-SAW |
Description | 23.8"Open Frame SAWTouch Monitor |
Case/Bezel Color | Steel/Black |
Display | 23.8'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
Optimal (native) Resolution | 1920×1080 @60Hz |
Useful Screen Area | 527.5mm × 297mm |
Colors | 16.7 M |
Brightness | 250cd/m2 |
Pixel Pitch | 276.75(per one triad) x 276.75 |
Response Time | 16ms |
Contrast Ratio | 3000:1 (Typical) |
| I/O Ports | USB Touch, OSD, VGA, HDMI, DisplayPort, 12V D/C in |
Viewing Angle(CR≥10) | Horizontal: ±89° or 178° total; Vertical: ±89° or 178° total |
| MTBF | 50000 hrs demonstrated |
Input Video Format | HDMI, VGA & Display Port |
Input Video Signal Connector | HDMI, VGA & Display Port |
Touch Technology | 10Point multitouch projected capacitive touch technology |
| Touch Point | One point |
| Protected Level | Dustproof and waterproof meet IP65 |
Touch Interface | USB touch interface |
Mounting Options | VESA Mount (75mm or 100mm) , Side Mount or Front Mount with optional bracket |
Power Supply | DC:+12VDC ± 5% |
External Adapter: 100-240VAC, 50-60Hz | |
Temperature Range | Operating: 0℃ to 50℃; Storage: -20℃ to 60℃ |
Humidity Range (no condensing) | Operating: 20%-80%; Storage: 10%-90% |
Dimension and Weight | Touch Monitor 561.6 x 325.8 x 44.1mm 7.15KGS |
Warranty | 1 year |
Agency Approvals | CCC, FCC, CE, RoHS |
