Model No: TM-5568

55inch IR touch monitor

55inch infrared multitouch Open Frame Touch Monitor

Quantity :

Contact Now

LeadingTouch TM-5568 is 55inch multitouch Infrared open frame touch monitor; cost-effective touch monitor; which is designed for Digital signage, Advertising machine,Kiosks,Gaming, Interactive digital,Industrial,Education,Transportation etc., is easily connected and integrated by user.

FEATURES

Superb cosmetic, slim housing;
On-Screen display (OSD);
Video Input VGA, DVI, HDIM options;

UHD 3840×2160 4K Display;

Anti-vandal 4mm physical tempered glass meet IK07;
Multitouch 10 Point infrared touch technology;

Video Input VGA, DVI, HDMI Options;
Standard VESA hole and four-side brackets.

Combinations of features indicate that LeadingTouch Touch Monitor is the best choice for you.

TM-5568 55" Infrared 10point Multitouch Open Frame Touch Monitor Specification
Model	TM-5568
Description	55"Infrared 10point FHD Touch Monitor
Case/Bezel Color	Metal Shell/Black
Display	55"diagonal, Active matrix TFT LCD
Aspect Ratio	16:9
Optimal (native) Resolution	3840×2160
Useful Screen Area	1215mm × 685.9mm
Colors	16.7 M
Brightness	500nits（500/1000/1500nits options)
Response Time	6ms (Typical)
Contrast Ratio	4000:1 (Typical)
Viewing Angle(CR≥10)	Horizontal: ±89° or 178° total; Vertical: ±89° or 178° total
MTBF	50000 hrs demonstrated
Input Video Format	VGA, DVI, HDMI Option
Input Video Signal Connector	VGA, DVI, HDMI Option
Touch Technology	Leadingtouch multitouch 10point infrared touch technology
Touch Point	Ture 10point multitouch
Protected Level	Anti-vandal 4mm galss meet IK07
OS	HID-Mode for windows 7/8/10/11, Android, Linux
Touch Interface	USB touch interface
Mounting Options	VESA Mount (300mm) , back bracket option
Power Supply	100-240VAC, 50-60Hz
Temperature Range	Operating: 0℃ to 50℃; Storage: -20℃ to 60℃
Humidity Range (no condensing)	Operating: 20%-80%; Storage: 10%-90%
Dimension and Weight	Touch Monitor 1284.2 x 755.1 x 67mm
Warranty	1 year
Agency Approvals	CCC, FCC, CE, RoHS
